FUEL INJECTION PUMPS

PUMP MODEL WITH HIGH AND LOW CAPACITY

FUEL INJECTION PUMPS are simple with port size being 1/2" suction X 1/2" Delivery. Mainly used for lubrication of machines, reduction gear boxes, by Railways and for transfer of oil, Capacity being 150 LPH 300 LPH, 450 LPH and 600 LPH. Maximum speed allowed for these pumps is 2900 RPM. They are available both in clockwise direction.

• FIG-LC-150-R-3H
• PUMP MODEL
• FIG-060-L-X02-K
• FIG-060-R-X02-K
• FEATURES

They are unmounted flanged type. Port sizes available being 1/2" suction X 1/2" delivery and 3/4" suction and 3/4" delivery. Mainly used on boilers and for burner application. Maximum speed allowed for lower capacity pumps is 2900 RPM and for High capacity pumps is 1500 RPM. Pumps are available both in clockwise and anticlockwise direction. Low capacity pumps are available with 150 LPH, 300 LPH, 450 LPH and 600 LPH. High capacity pumps are available with 1000 LPH, 1500 LPH, 2000 LPH and 2500 LPH.

• No leakage due to static 'O' Ring sealing
• Low cost in maintenance
• Precision Rotors are used in the pumps to give extra efficiency and increased durability.
• Rotors and Idlers Gears are precision machined to give balanced load.
• Fuel Injection Gear Pumps can easily be dismantled, working parts cleaned and greased and then reassembled to increased efficiency and longer life.
• You have a chance to make from variety of types and models of pumps offered by us.
